Techflex® Flexo® Wrap Braided Cable Sleeving
Side Entry (Wrap Around) Sleeving With Hook & Loop Closure
0.0 / 5
Techflex® Flexo® Wrap Braided Cable Sleeving Features
- Heavy Duty Hook & Loop Closure For Convenient Access
- Expands Easily to Fit Over Inline Connectors & Splices
- Cut & Abrasion Resistant
- Halogen Free
- Ideal For Multiple Cable Breakouts
Flexo wrap cable sleeve has a hook and loop fastener which makes it easy for the users to insert more wires and cables without complicating the existing connections over the entire bundle. This premium-grade cable sleeve is manufactured from polyethylene terephthalate monofilament material which has a high-temperature resistance. Its open expandable open weave design allows it to conform to a wide variety of bundle diameters even irregular shapes. Flexo wrap cable sleeving is a very efficient way of organizing your wires and cables. It is very durable and highly flexible.
Require Splice Free? Please Call 1877-284-7760
Inside Diameters Are Measured as Round Not Flat
Are we missing the specification you need? Please go to our Contact Us page and submit your question to us, or call 1-877-284-7760
| Nominal Size | Product Part # | Hook & Loop Width | Standard Spool Put-Ups | Colors | Lbs/ 100' | |
| Bulk | Shop | |||||
| 1/2" 3/4" 1 1/4" 2" 2 1/2" | FWN0.50 FWN0.75 FWN1.25 FWN2.00 FXN2.50BK | 1/4" 5/8" 5/8" 5/8" 5/8" | 100' 100' 100' 100' 100' | 20' 15' 12' 10' 10' | 4 4 4 4 BK | 1.30 1.80 2.30 3.20 3.7 |
| Physical Properties | |
| Monofilament Thickness (ASTM D-204) | .010 |
| Flammability Rating | |
| Recommended Cutting | Hot Knife |
| Colors | 4 |
| Wall Thickness | .025 |
| Tensile Strength - Yarn (ASTM D-2265) lbs. | 7.5 |
| Abrasion Resistance | Medium |
| Specific Gravity | 1.38 |
| Moisture Absorption % (ASTM D-570) | .1 - .2 |
| Chemical Resistance 1=No Effect 2=Little Effect 3=Affected 4=More Affected 5=Severely Affected | |
| Aromatic Solvents | 2 |
| Alipahtic Solvents | 1 |
| Chlorinated Solvents | 3 |
| Weak Bases | 1 |
| Strong Bases | 2 |
| Salt Water (O-S-1926) | 1 |
| Hydraulic Fluid (MIL-H-5606) | 1 |
| Lubricating Oil (MIL-L-7808) | 1 |
| De-Icing Fluid (MIL-A-8243) | 1 |
| Strong Acids | 3 |
| Strong Oxidants | 2 |
| Esters/Ketones | 1 |
| UV Light | 1 |
| Petroleum | 1 |
| Fungus (ASTM G-21) | 1 |
| Salts | 1 |
| Hard Vacuum Data (ASTM E-595 at 10-5 torr) | |
| TML | .19 |
| CVCM | .00 |
| WVR | .16 |
| Smoke D-Max (ASTM E-662) | 56 |
| Outgassing | Medium |
| Oxygen Index (ASTM D-2863) | 21 |
| Operating Temperatures | |
| Minimum Continuous | -94°F/-70°C |
| Maximum Continuous (MIL-I-23053) | 257°F/125°C |
| Melt (ASTM D-2117) | 482°F/250°C |
| Other Information | |
| Halogen Free | Yes |
| RoHS | Yes |
| SVHC | None |
| UL/CSA | Yes |
