Dunbar® 2:1 Diesel Resistant Heat Shrink Tubing
Available in 1/8" - 1-1/2" Diameters
0.0 / 5
Dunbar® Diesel Resistant Heat Shrink Features
- Highly Resistant To Aviation Fuels, Diesel Fuels, and Hydraulic Oils
- Continuous Operating Temperature: -75ºC (-103ºF) to 150ºC (302ºF)
- Flammability: ASTM D2671 Procedure B
- 4 mm Wall Thickness For Great Abrasion Resistance
- AMS-DTL-23053/16 (Formerly MIL-DTL-23053/16)
- RoHS Compliant
- Cross Reference To Other Manufacturers: Raychem: DR-25; Sumitomo R120;
- Canusa CDR625
- Please Note: Our Diameters for Heat Shrink Tubing are measured as ROUND TUBE, NOT FLAT.
Dunbar® Diesel resistant heat shrink tubing is made with flexible elastomer polyolefin tubing and is engineered to provide high resistance to these types of fluids. This heavy-duty automotive heat shrink tubing also protects your cables, wire harnesses from abrasive elements that could potentially cause damage. Our diesel-resistant heat-shrink is rated for military applications. Need a product to protect your wires or cables, and other electrical or mechanical components from diesel along with other aviation and hydraulic lubricating fluids? Look no more. For more detailed specifications, please click on the Specfications Tab.
Are we missing the specification you need? Please go to our Contact Us page and submit your question to us, or call 1-877-284-7760
| Properties | Methods | Values | ||
|---|---|---|---|---|
| Physical | Unaged | Tensile Strength | ASTM D412 | Min. 1700 psi |
| Elongation | Min. 250% | |||
| Tensile strength @100% Elongation | Max. 1500 psi | |||
| Aged | Tensile strength | 160℃/168 hrs | Min. 1500 psi | |
| Elongation | Min. 200% | |||
| Fluid Resist. | Tensile strength | 24℃/24 hrs 6 Fluids | Min. 1500 psi | |
| Elongation | Min. 200% | |||
| Dielectric strength | Min. 200V/mil | |||
| Low temperature flex | -65℃x4hrs | No cracks | ||
| Heat shock | 200℃x4hrs | No cracks, flowing, or dripping | ||
| Specific gravity | ASTM D792 | Max. 1.5 | ||
| Electrical | Dielectric strength | ASTM D2671 | Min. 300V / mil | |
| Volume resistivity | ASTM D876 | Min. 1x109Ω - cm | ||
| Chemical | Copper corrosion | 275℃/16hrs | No corrosion | |
| Fungus resistance | ASTM G21 | Rating less than 1 | ||
| Water Absorption | ASTM D570 | Max. 2.0 | ||
| Flammability | ASTM D2671 | Pass | ||
| Size | Expanded | Recovered | Standard Spool Length | ||||
|---|---|---|---|---|---|---|---|
| Internal Diameter (Minimum) (D) | Internal Diameter (Maximum) (D) | Minimum Wall Thickness (t) | |||||
| Inch Size | in. | mm | in. | mm | in. | mm | Ft. |
| 1/8" | 0.125 | 3.2 | 0.062 | 1.6 | 0.030 | 0.76 | 500 |
| 3/16" | 0.188 | 4.8 | 0.093 | 2.4 | 0.033 | 0.84 | 250 |
| 1/4" | 0.250 | 6.4 | 0.125 | 3.2 | 0.035 | 0.89 | 250 |
| 3/8" | 0.375 | 9.6 | 0.187 | 4.8 | 0.040 | 1.02 | 100 |
| 1/2" | 0.500 | 12.8 | 0.250 | 6.4 | 0.048 | 1.22 | 100 |
| 3/4" | 0.750 | 19.3 | 0.375 | 9.5 | 0.057 | 1.45 | 100 |
| 1" | 1.000 | 25.4 | 0.500 | 12.7 | 0.070 | 1.78 | 100 |
| 1-1/4" | 1.250 | 31.8 | 0.712 | 18.1 | 0.086 | 2.20 | 100 |
| 1-1/2" | 1.500 | 38.1 | 0.858 | 21.8 | 0.094 | 2.41 | 100 |
